Automatic Inspection Machine
NeoDen Inline AOI
NeoDen Inline AOI
Machine characteristics
1. HD color global exposure digital camera speed increase 30%.
2. High depth of field telecentric lens, which can measure the solder joints on the side of high components.
3. Support the detection of smt front, back and dip station.
4. Support 0201 and 01005 packaged component inspection.
5. CAD data import, automatic linking component library, automatic color picking.
6. True non-stop offline programming and program update.
7. MES data docking to realize intelligent factory.
8. Support multi-line centralized management and remote service.
Specification
NeoDen Inline AOI
Global exposure camera + telecentric lens
HD color global exposure digital camera speed increase 30%.High depth of field telecentric lens, which can measure the solder joints on the side of high components.
Board Bending Compensation
When the board is unevenly heated, resulting in a certain degree of deformation of the board.The CAD coordinates and the position of the board after passing through the oven cannot be accurately matched.After the plate bending is compensated, the coordinates and the corresponding positions of the components are accurate.
Compatible with Various Shapes of Pads
Wave soldering algorithm supports various shapes of pads, positioning is more accurate.
