NeoDen YY1 Pick and Place Machine

รหัสสินค้า : NeoDen YY1

ราคา

2,025.00 ฿

ราคารวม 2,025.00 ฿

Feature

1. NeoDen YY1 pick and place machine automatic nozzle changer help realizing nozzles changed flexibly.

2. Independent high-definition & high-speed dual vision recognition systems, as well as dual cameras for real-time display the working status.

3. NeoDne YY1 supports bulk component feeder, strip feeder and IC tray feeder.

4. Newly designed software system & UI for visual programming and placement, which allows fast programming on the machine, friendly interface & easy operation.

5. Works in a near-perfect silent mode, making it a green and pollution-free pick and place machine.


Specification

Placement Head: Gantry: 2 Nozzles

Tape Feeder: 52 (all 8mm)

Product name: NeoDen YY1 pick and place machine

Nozzle Change Capacity: 3 Nozzles

Machine Style: Single Gantry With 2 Heads

Component Range: Smallest Size: 0201 / Largest Size: 18*18mm / Max Height: 12mm

Placement Rate: Vision On: 3000CPH / Vision Off: 4000CPH

Feeder Capacity: Tape Feeder: 52 (all 8mm) / Flexible Feeder: 28 / Bulk Feeder: 19

Rotation: ±180°Stick Feeder: 4

External Dimensions: 643(L)x530(W)x601(H)mm

แบบฟอร์มสั่งซื้อ
ชื่อ *
นามสกุล *
อีเมล *
เบอร์ติดต่อ *
เมื่อท่านส่งข้อมูลผ่านฟอร์ม จะถือว่าท่านยอมรับใน นโยบายความเป็นส่วนตัว ของเรา

สินค้าไม่เพียงพอ

สินค้าหมด

สินค้าที่เกี่ยวข้อง
  • ขายดี
    NeoDen FP2636 Solder Paster Printer
    2,025.00 ฿
  • ขายดี
    NeoDen IN6 Desktop Reflow Oven
    2,025.00 ฿

NeoDen YY1 Pick and Place Machine

SMT Line YY1

NeoDen FP2636 Solder Paste Printer
NeoDen YY1 Pick and Place Machine
NeoDen IN6 Desktop Reflow Oven

User friendly touch screen

It comes with a high-definition capacitive touch screen,
which can be adjusted up and down to meet the needs of different viewing angles and enhance the user experiences.

 Dual vision system with built-in IC

Independent high-definition & high-speed dual vision recognition systems, as well as two cameras for real-time display the working status, the speed of processing components' photos becomes more efficient and accurate.

Powerful Magazines

Small size with powerful magazines and newly designed tape feeders to support large tape reels configur ation flexibly, easy to install and replace tape reels conveniently.

Vacuum detection and real-time display

Equipped with a vacuum detection function, can set standard vacuum detection values on placement head flexibly, all information can be displayed visually on the placement head.

Auto nozzle changer

It has 3 slots for nozzles replacement, which realizes maximum optimum of nozzles and achieve higher continuity of production.

Small Budget Production line

Desktop types small budget production line as start-up device for personal R&D
